Brand Name : | Crown Extra |
Model Number : | BYY |
Certification : | ATEX,CE,ROHS,CNEX,ISO9001 |
Price : | USD48-80per pc |
Payment Terms : | T/T |
Supply Ability : | 50000pcs/month |
Delivery Time : | 15 working days |
3W 100lm/w waterproof IP65 explosion proof LED emergency warning light Exit Sign explosion-proof light
BYY Series
Features:
Applications
Explosive hazardous atmosphere Zone 1, 2 & Zone 21,22 |
Widely used for safety exit indication and marking on various marine platforms, chemical tankers, LNG ships and dangerous cargo wharfs ect. |
Can reliably work in severe environment where is easily affected by moisture, vibration, or corrosion. |
Housing: | Die-casting aluminum |
Exterior: | Stainless steel |
Globe: | Tempered glass |
Gasket: | Silicon rubber |
Certifications | ATEX CNEX CE RoHS ISO9001 |
Ex Marking | Ex e IIC T6/ Ex tD A21 T80℃ |
Application | Zone 1, 2 & Zone 21, 22 |
IP Degree | IP65 |
Corrosion Resistant | WF1 |
Wattage | 1.5-3W |
Entries | G 3/4" Conduit Entry, Suitable for Φ10mm-Φ14mm cable |
Input Voltage | DC 110V;AC220V 50Hz |
Red Lettering | Optiional |
Back-up Battery | >120 min |
Weight | 3.25kg |
Mounting Styles | Pendant; Ceiling; wall |
Installation Instructions:
Before installation, check voltage, power and other parameters
carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is
installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light
finally
Company information:
Crown Extra Lighting Co., Ltd. is a comprehensive enterprise
integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in
the Yangtze River
Delta of China. The company is committed to becoming a provider of
green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing
high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways,
aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional
technical service programs.
FAQ:
Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..
Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof
fittings, etc.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q5: What's the MOQ?
A:MOQ is 1 set.
![]() |
